Allen-Bradley Stratix 5700 User Manual

482 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Appendix A Data Types
AnyPortUnauthorizedDevice BOOL Indicates that an unauthorized MAC ID has attempted to
communicate on any port.
PortGi1_1UnauthorizedDevice BOOL Indicates that an unauthorized MAC ID has attempted to
communicate on a particular port.
0 = No mismatch
1 = Mismatch
PortGi1_2UnauthorizedDevice BOOL
PortFa1_1UnauthorizedDevice BOOL
PortFa1_2UnauthorizedDevice BOOL
PortFa1_3UnauthorizedDevice BOOL
PortFa1_4UnauthorizedDevice BOOL
PortFa1_5UnauthorizedDevice BOOL
PortFa1_6UnauthorizedDevice BOOL
PortFa1_7UnauthorizedDevice BOOL
PortFa1_8UnauthorizedDevice BOOL
PortFa2_1UnauthorizedDevice BOOL
PortFa2_2UnauthorizedDevice BOOL
PortFa2_3UnauthorizedDevice BOOL
PortFa2_4UnauthorizedDevice BOOL
PortFa2_5UnauthorizedDevice BOOL
PortFa2_6UnauthorizedDevice BOOL
PortFa2_7UnauthorizedDevice BOOL
PortFa2_8UnauthorizedDevice BOOL
PortFa3_1UnauthorizedDevice BOOL
PortFa3_2UnauthorizedDevice BOOL
PortFa3_3UnauthorizedDevice BOOL
PortFa3_4UnauthorizedDevice BOOL
PortFa3_5UnauthorizedDevice BOOL
PortFa3_6UnauthorizedDevice BOOL
PortFa3_7UnauthorizedDevice BOOL
PortFa3_8UnauthorizedDevice BOOL
AnyPortThreshold BOOL Indicates that unicast, multicast, or broadcast threshold limit has
been exceeded on any port.
Table 158 - Input Data Types (continued)
Tag Name Type Description

Allen-Bradley Stratix 5700 Specifications

General

Model	Stratix 5700
Port Types	RJ45, SFP
Mounting	DIN Rail or Panel Mount
Dimensions	Varies by model
Weight	Varies by model
Management	Web-based, SNMP, Command Line
Redundancy	Device Level Ring, STP, RSTP
Operating Temperature	-40°C to 70°C
Power Supply	Dual DC inputs
Input Voltage	24 VDC or 100-240 VAC
Protocols	EtherNet/IP, DLR
Security Features	SSH, HTTPS, RADIUS, TACACS+
