Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 483
Data Types Appendix A
PortGi1_1Threshold BOOL Indicates that unicast, multicast, or broadcast threshold limit has
been exceeded on a particular port.
0 = OK
1 = Threshold exceeded
PortGi1_2Threshold BOOL
PortFa1_1Threshold BOOL
PortFa1_2Threshold BOOL
PortFa1_3Threshold BOOL
PortFa1_4Threshold BOOL
PortFa1_5Threshold BOOL
PortFa1_6Threshold BOOL
PortFa1_7Threshold BOOL
PortFa1_8Threshold BOOL
PortFa2_1Threshold BOOL
PortFa2_2Threshold BOOL
PortFa2_3Threshold BOOL
PortFa2_4Threshold BOOL
PortFa2_5Threshold BOOL
PortFa2_6Threshold BOOL
PortFa2_7Threshold BOOL
PortFa2_8Threshold BOOL
PortFa3_1Threshold BOOL
PortFa3_2Threshold BOOL
PortFa3_3Threshold BOOL
PortFa3_4Threshold BOOL
PortFa3_5Threshold BOOL
PortFa3_6Threshold BOOL
PortFa3_7Threshold BOOL
PortFa3_8Threshold BOOL
AllPortsUtilization SINT The sum of the percentage of the bandwidth utilized of all ports on
the switch.
Table 158 - Input Data Types (continued)
