Programming the Hold Step Type
The Hold Step Type allows the user to pause a cycle at a specific
type to allow user interaction with the cycle, generally to add a
chemical. After selecting the desired Cycle Step number and
pressing START (enter), XXHoLd will appear in the display.
Press the Delicates Bulky (∧) or the Cold (∨) keypad to scroll
through the options and START (enter) to select a value.
NOTE: To go back to the current programmable option
without changing the value of the active digit, press the
Warm (<) keypad.
Step
Type
Display
A Display B Values Description
XXHoLd Hold Step Type (XX is step number, step type is flash-
ing)
En diS XXHo01 EnAbLe/diSAbL/dNod 1/
dNod 2
Step Enable/Disable
Choosing dNod 1 and dNod 2 will enable the step
if the cycle modifier is chosen and set to be enabled
in Cycle Modifier Programming Menu CNP-.
StAtUS XXHo02 PrEWSH/WASH/rinSE1/
rinSE2/rinSE3/rinSE4/
SPin
Status LED: The corresponding LED on the control
will be lit during this step.
NinUtE XXHo03
0-2 Step Minutes: If Programmed Cycle Time Display is
enabled and set to a value greater than zero, it will
override this time.
SECond XXHo04
0-59 Step Seconds: If Programmed Cycle Time Display is
enabled and set to a value greater than zero, it will
override this time.
AUdioP XXHo05
0-20 Audio Pattern: The audio will stop once a key is
pressed or the door is opened.
NESSAg XXHo06 LoAd/CHEN, SoAP,
bLEACH/SoFtnr/SoUr/
StArCH/CUStN1/CUStN2
Display Message
StArtP XXHo07 StrtCy/UnLoCK
Door Lock State
AUrESN XXHo08
0-255 Automatic Resume Minutes: Cycle will resume auto-
matically after the programmed time only if the step
was programmed to have the door remain locked.
drAin1 on/oFF
Drain #1
drAin2 on/oFF
Drain #2
oUtP 1 XXHo12 on/oFF
External Output #1
oUtP 2 XXHo13 on/oFF
External Output #2
oUtP 3 XXHo14 on/oFF
External Output #3
oUtP 4 XXHo15 on/oFF
External Output #4
Table 24
While in the Hold Step, a message is used to indicate what inter-
action the machine is waiting for. The Hold step can be program-
med to either hold water and keep the door locked or to evacuate
water and unlock the door. In both cases a Start key press will al-
low the cycle to resume.
This step may be used to allow the machine to be rinsed out be-
fore adding the next load. An additional vend could be charged
Programming Control
©
