Step
Type
Display
A Display B Values Description
SPEEd XXFi11 no rot/LoW Ag/rEg Ag/
10-50 RPM (X.XX-X.XX G
Force)
Rotation Speed: no rotation, low agitate speed, regu-
lar agitate speed or custom speed in RPM/G Force
• 0.03-0.75 for 20 pound
• 0.04-0.86 for 30 pound
• 0.04-0.94 for 40 pound
• 0.05-1.07 for 60 pound
• 0.06-1.27 for 80 pound
• 0.06-1.27 for 100 pound
rEvErS XXFi12 rEv on/no rEv
Reversing
FiLL XXFi13 on/oFF
Fill Valves
Fi tUb XXFi14 on/oFF
Tub Fill Valves (if so equipped)
SPrAY XXFi15 on/oFF
Spray Valves (if so equipped)
C HArd XXFi16 on/oFF
Cold Hard Fill Valve (if so equipped)
AUX FL XXFi17 on/oFF
Auxiliary Fill Valve (if so equipped)
Table 14
Programming Control
©
