Programming the Fill Step Type
The Fill Step Type allows the owner to program the Fill Steps of
a cycle. After selecting the desired Cycle Step number and press-
ing START (enter), XXFiLL will appear in the display. Press the
Delicates Bulky (∧) or the Cold (∨) keypad to scroll through the
options and START (enter) to select a value.
NOTE: To go back to the current programmable option
without changing the value of the active digit, press the
Warm (<) keypad.
Step
Type
Display
A Display B Values Description
XXFiLL Fill Step Type (XX is step number, step type is flash-
ing)
En diS XXFi01 EnAbLe/diSAbL/dNod 1/
dNod 2
Step Enable/Disable
Choosing dNod 1 and dNod 2 will enable the step
if the cycle modifier is chosen and set to be enabled
in Cycle Modifier Programming Menu CNP-.
StAtUS XXFi02 PrEWSH/WASH/rinSE1/
rinSE2/rinSE3/rinSE4/
SPin
Status LED: The corresponding LED on the control
will be lit during this step.
NinUtE XXFi03
0-255 Step Minutes: If Programmed Cycle Time Display is
enabled and set to a value greater than zero, it will
override this time.
SECond XXFi04
0-59 Step Seconds: If Programmed Cycle Time Display is
enabled and set to a value greater than zero, it will
override this time.
LEvEL XXFi05 LoW/NEd/HigH/1-30
Water Level: Low, Medium and High levels are glob-
ally programmed or a custom fill level from 1-30.
Each increment is the same amount where 1 corre-
sponds to the lowest programmable level and 30 is
the highest programmable level.
v tENP XXFi06 CoLd/WArN/Hot
Water Valve Temperature: Cold (cold valve), Warm
(cold and warm valves), Hot (hot valves)
W tENP XXFi07 g CoLd/g WArM/g Hot
Water Temperature (heat models): Cold, Warm or Hot
are globally programmed or a custom temperature.
FLUSH XXFi08 no/yES
Flush Out: Evacuates water at the beginning of the
step for the globally programmed time which helps
clean out the tub and prevent the excess dirty water
from mixing with the fresh water.
rotAtE XXFi09
3-255 Motor On Time (seconds)
PAUSE XXFi10
3-255 Motor Off Time (seconds)
