Programming the Agitate Step Type
The Agitate Step Type allows the owner to program the agitate
steps of a cycle. After selecting the desired Cycle Step number
and pressing START (enter), XXAgit will appear in the display.
Press the Delicates Bulky (∧) or the Cold (∨) keypad to scroll
through the options and START (enter) to select a value.
NOTE: To go back to the current programmable option
without changing the value of the active digit, press the
Warm (<) keypad.
Step
Type
Display
A Display B Values Description
XXAgit Agitate Step Type (XX is step number, step type is
flashing)
En diS XXAg01 EnAbLe/diSAbL/dNod 1/
dNod 2
Step Enable/Disable
Choosing dNod 1 and dNod 2 will enable the step
if the cycle modifier is chosen and set to be enabled
in Cycle Modifier Programming Menu CNP-.
StAtUS XXAg02 PrEWSH/WASH/rinSE1/
rinSE2/rinSE3/rinSE4/
SPin
Status LED: The corresponding LED on the control
will be lit during this step.
NinUtE XXAg03
0-255 Step Minutes: If Programmed Cycle Time Display is
enabled and set to a value greater than zero, it will
override this time.
SECond XXAg04
0-59 Step Seconds: If Programmed Cycle Time Display is
enabled and set to a value greater than zero, it will
override this time.
HEAt XXAg05 no/tArgEt/MAintA
Heater Temperature (refer to Heating/Cool Down Dis-
play Sequence (Heat Models))
rAtE XXAg06 no/0.5-6.0°F/Minute
[0.3-3.3°C/Minute]
Heat Rate (heat models)
rotAtE XXAg07
3-255 Motor On Time (seconds)
PAUSE XXAg08
3-255 Motor Off Time (seconds)
SPEEd XXAg09 no rot/LoW Ag/rEg Ag/
10-50 RPM (X.XX-X.XX G
Force)
Rotation Speed: no rotation, low agitate speed, regu-
lar agitate speed or custom speed in RPM/G Force
• 0.03-0.75 for 20 pound
• 0.04-0.86 for 30 pound
• 0.04-0.94 for 40 pound
• 0.05-1.07 for 60 pound
• 0.06-1.27 for 80 pound
• 0.06-1.27 for 100 pound
rEvErS XXAg10 rEv on/no rEv
Reversing
drAin1 XXAg11 on/oFF
Drain #1
drAin2 XXAg12 on/oFF
Drain #2
Table 19 continues...
