Step
Type
Display
A Display B Values Description
oUtP 1 XXSU19 on/oFF
External Output #1
oUtP 2 XXSU20 on/oFF
External Output #2
oUtP 3 XXSU21 on/oFF
External Output #3
oUtP 4 XXSU22 on/oFF
External Output #4
Table 16
Supply Steps are unique in that they can either be run independ-
ently or be tied to a Fill Step or a Reuse Fill Step. The following
tables are examples of when the Supply step will be active. All
steps below are shown as enabled, other disabled steps may exist
in between shown steps.
When Supply Step is active with a Fill Step, Supply Step time is
not counted towards total cycle time. Supply steps act as their
own step any time an enabled Fill Step does not directly precede
the enabled Supply Steps.
Steps When active
Step 1 Fill Step
Step 2 Supply Step Active with Step 1
Step 3 Supply Step Active with Step 1
Step 4 Agitate Step
Step 1 Fill Step
Step 2 Agitate Step
Step 3 Supply Step Acts as own step
Step 4 Supply Step Acts as own step
Step 5 Extract Step
Table 17
Steps When active
Step 1 Supply Step Acts as own step
Step 2 Fill Step
Step 3 Supply Step Active with Step 2
Step 4 Agitate Step
Step 1 Fill Step
Step 2 Agitate Step
Step 3 Supply Step Acts as own step
Step 4 Fill Step
Step 5 Supply Step Active with Step 4
Table 18
Programming Control
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
90 Part No. F8615401ENR4
