Figure 4-14 Traffic Distribution Statistics
Tx%(Avg) ：Average transmitted packets percentage
Rx%(Avg) ：Average receive packets percentage
Busy%(Avg) ：Average busy time percentage
Noise Floor(dBm) ：5GHz noise floor in A2n surrounding environment
CTL0：Chain 0 Noise Floor of the Control Channel (i.e the operating channel for HT20)
CTL1：Chain 1 Noise Floor of the Control Channel (i.e the operating channel for HT20)
EXT0：Chain 0 Noise Floor of the Extension Channel (i.e the +/- channel of the HT40)
