EXT1：Chain 1 Noise Floor of the Extension Channel (i.e the +/- channel of the HT40)
Interference Mitigation Offset (0-50dB) ：This option will mask all noise / valid signal
below "0-50" dB.
4.2.2.4. WLAN
Please select Status -> Interface-> Radio1(5G) -> WLAN to check Radio1(5G) wireless
network information which includes Device ID, WLAN ID, SSID, MAC Address, Auth
Mode, Unicast Cipher, Multicast Cipher, Num of Station, Throughput (Tx/Rx), Traffic
(Tx/Rx) and State.
When you enable a WLAN, you can find its relevant information in “State”.
Figure 4-15 5G interface WLAN information
Device Id：5G interface ID
WLAN： Wireless LAN number
SSID： A2n default SSID is “Superwifi Network x” (x is from 0 to 15)
MAC Address： 5G wireless network MAC address (BSSID)
Auth Mode： Authentication mode for each wireless network
Unicast Cipher ：Unicast cipher mode for each wireless network
Multicast Cipher ： Multicast cipher mode for each wireless network
Num of Station： Associated client number
Throughput（TX/RX）：Real Throughput of transmitted and received packets for
each wireless network
Traffic (Tx/Rx)：Download and Upload packets for each wireless network
State：Wireless network state
4.2.2.5. Association List
Please select Status -> Interface-> Radio1(5G) -> Association List to get associated
