Enable WLAN ：Enable or Disable WLAN from 0-15.
Hide SSID：By default, it is disabled.
SSID：Support maximum 32 characters, default SSID is：Superwifi Network X, X is
WLAN number.
Max Clients：Max. Associated clients
Isolation： Enable or Disable inter-WLAN communication isolation. By default, it is
enable.
VLAN Pass-Through/ID： Set VLAN pass through or VLAN TagID this WLAN
Auth Mode: The authentication mode set for WLAN.
Access Traffic Right：Access traffic right controls associated stations the ability to
permit or deny AP management.
WLAN Uplink/Downlink Control： This option control the uplink and downlink speed for
this WLAN.
Station Uplink/Downlink Control： This option control the uplink and downlink speed
for the stations which associate to this WLAN.
Select Configuration -> Wireless -> Radio1 (5G) -> WLAN to click “More…” behind the
WLAN, and then select WLAN General.
Figure 5-50 5GHz AP WLAN Detail Setting
