6. Redundancy with NX3030 CPU
333
Redundancy Diagnostics
The Redundancy Diagnostics may have several uses, such as:
 They can be consulted in order to verify the existence of a problem that needs to be solved
 Every time there are variations on them, such variations are inserted as events in the
“Redundancy Event Log”. Consulting the history sequence of such events, a switchover cause
may be discovered, for instance
 They can be referenced in the user application (ActivePrg or NonSkippedPrg). E.g. the PLC state
can be tested and in case it’s not active, a MODBUS RTU serial master I/O driver can be
disabled, in NonSkippedPrg
ATTENTION:
The _NX4010.tRedundancy.RedDgnLoc.sGeneral_Diag.bExchangeSync (defined next) must be
tested to verify if the data structure RedDgnRem was successfully read from the remote PLC in the
last MainTask cycle. In case this diagnostic value is 0 (false), this means the data structure
RedDgnRem wasn’t successfully read from the remote PLC, thus the RedDgnRem values may be
invalid or obsolete.
As RedDgnRem is a copy from the other PLC RedDgnLoc, it can be concluded the two structures
have the same format. These are divided in other four substructures:
 sGeneral_Diag: Redundancy general diagnostics
 sNETA_Diag: NETA synchronism channel diagnostics
 sNETB_Diag: NETB synchronism channel diagnostics
 sNET_Stat: Common statistics for the synchronism channels NETA and NETB, for failure and
success counting in the synchronization services
 sGeneral_DiagExt: Redundancy general diagnostics, extended part (continuing of
sGeneral_Diag).
The “sGeneral_Diag” substructure has the following fields for redundancy general diagnostics:
Direct Representation
Variable
AT variable
DG_NX4010.tRedundancy.R
edDgnLoc.sGeneral_Diag.*
Description
Variable
Bit
%QB(n+4)
0
bConfigDone
TRUE – The configuration process, executed in
the Not-Configured state, has finished.
FALSE – The configuration process, executed in
the Not-Configured state, hasn’t finished yet or
wasn’t executed.
1
bConfigError
TRUE – the configuration process, executed in
the Not-Configured state, has finished with
errors. It’s a system error, normally not expected.
Get in contact with ALTUS support to report it.
Also inform the ConfigErrorCode diagnostic
value for the ALTUS support.
FALSE – The configuration process has finished
successfully or wasn’t executed.
2
bTooManyRedAreas
TRUE – The number of redundant areas
exceeded the maximum allowed. It’s a system
error, normally not expected. Get in contact with
ALTUS support to report it.
FALSE – The number of redundant areas is
within the expected.
3
bTemporaryBufferTooSmall
TRUE – Intermediate data structure with
insufficient size. It’s a system error, normally not
expected. Get in contact with ALTUS support to
report it.
FALSE – Intermediate data structure is within the
expected.
4
bExchangeSync
TRUE – The Diagnostic and Commands
Exchange synchronization service was executed
