ALTUS Nexto NX3004 User Manual

7. Maintenance
355
Direct Representation
Variable
Diagnostics
Message
DG_Modulo.tSummarized.
* AT Variable
Description
Variable
Bit
FALSE – The hardware is working
properly.
1.1
SOFTWARE
EXCEPTION
bSoftwareException
TRUE – One or more exceptions
generated by the software.
FALSE – No exceptions generated in
the software.
1.2
bReserved_10
Reserved
1.3
ERROR IN
MEMORY CARD
bMemoryCardError
TRUE – The memory card is inserted
in the CPU, but is not working properly.
FALSE – The memory card is working
properly.
1.4
COM1 CONF.
ERROR
bCOM1ConfigError
TRUE – Some error occurred during,
or after, the COM 1 serial interface
configuration.
FALSE – The COM 1 serial interface
configuration is correct.
1.5
COM2 CONF.
ERROR
bCOM2ConfigError
TRUE – Some error occurred during,
or after, the COM 2 serial interface
configuration.
FALSE – The COM 2 serial interface
configuration is correct.
1.6
NET1 CONF.
ERROR
bNET1ConfigError
TRUE – Some error occurred during,
or after, the NET 1 Ethernet interface
configuration.
FALSE – The NET 1 Ethernet interface
configuration is correct.
1.7
NET2 CONF.
ERROR
bNET2ConfigError
TRUE Some error occurred during or
after the NET 2 Ethernet interface.
FALSE – The NET 2 Ethernet interface
configuration is not correct.
%QB(n+2)
2.0
INVALID
DATE/TIME
bInvalidDateTime
TRUE – The date or hour are invalid.
FALSE – The date or hour are correct.
2.1
RUNTIME
RESET
bRTSReset
TRUE – The RTS (Runtime System)
has been restarted at least once. This
diagnostics is only cleared in the
system restart.
FALSE – The RTS (Runtime System)
is operating normally.
2.2
OTD SWITCH
ERROR
bOTDSwitchError
TRUE – True in case the OTD key has
been locked for more than 20 s at least
once while the CPU was energized.
This diagnostic is only cleared in the
system restart.
FALSE – The key is not currently
locked or was locked while the CPU
was energized.
2.3 a 2.7
bReserved_xx
Reserved
%QB(n+3)
3.0
ABSENT RACK
bAbsentRacks
TRUE – One or more declared racks
are absent.
FALSE – There are no absent racks.
3.1
DUPLICATED
RACK
bDuplicatedRacks
TRUE – There are racks with a
duplicated identification number.
FALSE – There are no racks with a
duplicated identification number.
3.2
INVALID RACK
bInvalidRacks
TRUE – There are racks with an
invalid identification number.
FALSE – There are no racks with an
invalid identification number.
3.3
NON
bNonDeclaredRacks
TRUE – There are racks with a non-
