7. Maintenance
367
CPU Direct Representation Variable
Size
DG_Modulo.tDetailed.*
AT Variable
Description
NX3004
NX3005
NX3010
NX3020
NX3030
%QX(n+532).0
%QX(n+633).0
BIT
SNTP.
bServiceEnabled
SNTP Service enabled.
%QB(n+533)
%QB(n+634)
BYTE
SNTP.
byActiveTimeServer
Indicates which server is active:
00: None active server.
01: Active Primary Server.
02: Active Secondary Server.
%QW(n+534)
%QW(n+635)
WORD
SNTP.
wPrimaryServerDownCo
unt
Counter of times in which the
primary server is unavailable. (0 to
65535)
%QW(n+536)
%QW(n+637)
WORD
SNTP.
wSecondaryServerDow
nCount
Counter of times in which the
secondary server is unavailable.
(0 to 65535)
%QD(n+538)
%QD(n+639)
DWORD
SNTP.
dwRTCTimeUpdatedCo
unt
Counter of times the RTC was
updated by the SNTP service. (0
to 4294967295)
%QB(n+542)
%QB(n+643)
BYTE
SNTP.
byLastUpdateSuccessfu
l
Indicates status of the last update:
00: It was not updated.
01: Last update failed.
02: Last update was successfully.
%QB(n+543)
%QB(n+644)
BYTE
SNTP.
byLastUpdateTimeServ
er
Indicates which server was used
in the last update:
00: None update.
01: Primary Server.
02: Secondary Server.
%QB(n+544)
%QB(n+645)
BYTE
SNTP.
sLastUpdateTime.byDay
OfMonth
Day of the last update of the RTC.
%QB(n+545)
%QB(n+646)
BYTE
SNTP.sLastUpdateTime
.byMonth
Month of the last update of the
RTC.
%QW(n+546)
%QW(n+647)
WORD
SNTP.sLastUpdateTime
.wYear
Year of the last update of the
RTC.
%QB(n+548)
%QB(n+649)
BYTE
SNTP.sLastUpdateTime
.byHours
Hour of the last update of the
RTC.
%QB(n+549)
%QB(n+650)
BYTE
SNTP.sLastUpdateTime
.byMinutes
Minute of the last update of the
RTC.
%QB(n+550)
%QB(n+651)
BYTE
SNTP.bReservedAlign
Reserved
%QB(n+551)
%QB(n+652)
BYTE
SNTP.sLastUpdateTime
.bySeconds
Second of the last update of RTC.
%QW(n+552)
%QW(n+653)
WORD
SNTP.sLastUpdateTime
.wMilliseconds
Millisecond of the last update of
RTC.
%QW(n+554)
%QW(n+655)
WORD
SNTP.wReserved_0
Reserved
%QW(n+556)
%QW(n+657)
WORD
SNTP.wReserved_1
Reserved
Table 7-25. SNTP Detailed Diagnostics Group Description
CPU Direct Representation Variable
Size
DG_Modulo.tDetailed.*
AT Variable
Description
NX3004
NX3005
NX3010
NX3020
NX3030
NA
%QX(n+659).0
BIT
SOE[1].
bConnectionStatus
Connection status of client 01
NA
%QX(n+659).1
BIT
SOE[1].
bOverflowStatus
Queue status of client events 01
FALSE – There was no overflow
TRUE – Exceeded queue limit
NA
%QB(n+660)
BYTE
SOE[1].
byReserved_0
Reserved
NA
%QW(n+661)
WORD
SOE[1].
wEventsCounter
Counter of events in the client
queue 01
NA
%QX(n+663).0
BIT
SOE[2].
bConnectionStatus
Connection status of client 02
