APPENDIX D: RS-485 COMMUNICATION
LW500A/LW600A PULSED Nd:YAG LASER
990-539 D-7
85 Schedule Settings for FIX mode (continued)
DATA No. ITEM DATA RANGE
10 Not Used
Fixed to 0000
11*
Reads approximate Laser Output Energy [REFERENCE VALUE]
on the [SCHEDULE] screen. Can only be read, cannot be set.
0000 – 9999 (x 0.1J)
12 Set [COOL 1] Time on the [SCHEDULE] screen
000–999 (x 0.1ms/0.01ms)
1
13 Set [COOL 2] Time on the [SCHEDULE] screen
000–999 (x 0.1ms/0.01ms)
1
Note 1: The resolution (x 0.1ms) or (x 0.01ms) depends on the position of SW1-7 in the Initialization Screen.
86 Schedule Settings for FLEX mode – Time (01 – 10)
DATA No. ITEM DATA RANGE
01 Set [POINT 01] Time on the [SCHEDULE] screen 000–999 (x 0.1ms/0.01ms)
1
02 Set [POINT 02] Time on the [SCHEDULE] screen 000–999 (x 0.1ms/0.01ms)
1
03 Set [POINT 03] Time on the [SCHEDULE] screen 000–999 (x 0.1ms/0.01ms)
1
04 Set [POINT 04] Time on the [SCHEDULE] screen 000–999 (x 0.1ms/0.01ms)
1
05 Set [POINT 05] Time on the [SCHEDULE] screen 000–999 (x 0.1ms/0.01ms)
1
06 Set [POINT 06] Time on the [SCHEDULE] screen 000–999 (x 0.1ms/0.01ms)
1
07 Set [POINT 07] Time on the [SCHEDULE] screen 000–999 (x 0.1ms/0.01ms)
1
08 Set [POINT 08] Time on the [SCHEDULE] screen 000–999 (x 0.1ms/0.01ms)
1
09 Set [POINT 09] Time on the [SCHEDULE] screen 000–999 (x 0.1ms/0.01ms)
1
10 Set [POINT 10] Time on the [SCHEDULE] screen 000–999 (x 0.1ms/0.01ms)
1
11*
Reads approximate Laser Output Energy [REFERENCE VALUE] or
[~] on the [SCHEDULE] screen (can be read but not set).
0000 – 9999 (x 0.1J)
Note 1: The resolution (x 0.1ms) or (x 0.01ms) depends on the position of SW1-7 in the Initialization Screen.
