APPENDIX D: RS-485 COMMUNICATION
LW500A/LW600A PULSED Nd:YAG LASER
D-8 990-539
87 Schedule Settings for FLEX mode – Time (11 – 20)
DATA No. ITEM DATA RANGE
01 Set [POINT 11] Time on the [SCHEDULE] screen
000–999 (x 0.1ms/0.01ms)
1
02 Set [POINT 12] Time on the [SCHEDULE] screen
000–999 (x 0.1ms/0.01ms)
1
03 Set [POINT 13] Time on the [SCHEDULE] screen
000–999 (x 0.1ms/0.01ms)
1
04 Set [POINT 14] Time on the [SCHEDULE] screen
000–999 (x 0.1ms/0.01ms)
1
05 Set [POINT 15] Time on the [SCHEDULE] screen
000–999 (x 0.1ms/0.01ms)
1
06 Set [POINT 16] Time on the [SCHEDULE] screen
000–999 (x 0.1ms/0.01ms)
1
07 Set [POINT 17] Time on the [SCHEDULE] screen
000–999 (x 0.1ms/0.01ms)
1
08 Set [POINT 18] Time on the [SCHEDULE] screen
000–999 (x 0.1ms/0.01ms)
1
09 Set [POINT 19] Time on the [SCHEDULE] screen
000–999 (x 0.1ms/0.01ms)
1
10 Set [POINT 20] Time on the [SCHEDULE] screen
000–999 (x 0.1ms/0.01ms)
1
11*
Reads approximate Laser Output Energy [REFERENCE VALUE]
or [~] on the [SCHEDULE] screen (can be read but not set).
0000 – 9999 (x 0.1J)
Note 1: The resolution (x 0.1ms) or (x 0.01ms) depends on the position of SW1-7 in the Initialization Screen.
88 Schedule Settings for FLEX mode – Power (01 – 10)
DATA No. ITEM DATA RANGE
01 Set [POINT 01] Power on the [SCHEDULE] screen 0000 – 2000 (x 0.1%)
02 Set [POINT 02] Power on the [SCHEDULE] screen 0000 – 2000 (x 0.1%)
03 Set [POINT 03] Power on the [SCHEDULE] screen 0000 – 2000 (x 0.1%)
04 Set [POINT 04] Power on the [SCHEDULE] screen 0000 – 2000 (x 0.1%)
05 Set [POINT 05] Power on the [SCHEDULE] screen 0000 – 2000 (x 0.1%)
06 Set [POINT 06] Power on the [SCHEDULE] screen 0000 – 2000 (x 0.1%)
07 Set [POINT 07] Power on the [SCHEDULE] screen 0000 – 2000 (x 0.1%)
08 Set [POINT 08] Power on the [SCHEDULE] screen 0000 – 2000 (x 0.1%)
09 Set [POINT 09] Power on the [SCHEDULE] screen 0000 – 2000 (x 0.1%)
10 Set [POINT 10] Power on the [SCHEDULE] screen 0000 – 2000 (x 0.1%)
11*
Reads approximate Laser Output Energy [REFERENCE VALUE]
or [~] on the [SCHEDULE] screen (can be read but not set).
0000 – 9999 (x 0.1J)
