Amazone Cirrus 3000 User Manual

Maintenance, repair and care work
130
Cirrus 3/4/6000 DB2034 08.04
after the first 10 hours of operation
• retighten bolts.
for bolt torques see table (Fig. 215).
Thread Spanner width
Torque (Nm)
in relation to the grade of bolts' / nuts
8.8 10.9 12.9
M 8 13 25 35 41
M 8x1 13 27 38 41
M 10 17 49 69 83
M 10x1 17 52 73 88
M 12 19 86 120 145
M 12x1,5 19 90 125 50
M 14 22 135 190 230
M 14x1,5 22 150 210 250
M 16 24 210 300 355
M 16x1,5 24 225 315 380
M 18 27 290 405 485
M 18x1,5 27 325 460 550
M 20 30 410 580 690
M 20x1,5 30 460 640 770
M 22 32 550 780 930
M 22x1,5 32 610 860 1050
M 24 36 710 1000 1200
M 24x2 36 780 1100 1300
M 27 41 050 1500 1800
M 27x2 41 1150 1600 1950
M 30 46 1450 2000 2400
M 30x2 46 1600 2250 2700
Fig. 215
