Introduction User manual
System component Description
Profiler FX
Profile Measuring instrument
Measures single points or complete profiles
automatically relative to the track axis. In
combination with external positioning (by a
total station, GNSS System or AMU 1030,
AMU 2010 and AMU 2030), the absolute
coordinates of the measured points are
provided.
GPA 100
Prism adaptor
For the installation of a prism on the Profiler
FX or on the Prism Column GPC 100.
Profiler FX
Transport case
The protection case for delivery and
transportation of the Profiler FX.
Adaptor Plate AMU
Adaptor plate for the 2-wheel-part
The base plate and all necessary parts to
install the AMU on the 2-wheel-part of the
TGS FX trolley.
Adaptor Plate GNSS Antenna Pole
Adaptor plate for the 2-wheel-part
The base plate and all necessary parts to
install the GNSS Antenna Pole on the 2-
wheel-part of the TGS FX trolley.
