User manual Introduction
System component Description
GPC 100
Prism Column
For the installation of the prism on the
track trolley. The prism is positioned at the
optimum height above the track.
AMU 1030
Amberg Measuring Unit
The Amberg Measurement Unit is used
for the configurations IMS 1000, IMS
3000 and IMS 5000. The integrated high-
performance Inertial Measurement Unit
(IMU) and microcomputer are used for
measuring the track geometry.
AMU 2010
Amberg Measuring Unit
This AMU system is mainly used for the
configurations IMS 1000 and IMS 3000.
The integrated high-performance Inertial
Measurement Unit (IMU) and microcomputer
are used for measuring the track geometry.
AMU 2030
Amberg Measuring Unit
This AMU system is used for the
configurations IMS 1000, IMS 3000 and
IMS 5000. The integrated high-performance
Inertial Measurement Unit (IMU) and
microcomputer are used for measuring the
track geometry.
© Amberg Technologies AG, 2023 Page 21 of 114
