Reinstalling the Electronics Module
Once you have serviced the various components in the Electronics Module,
reassemble the analyzer.
1. Carefully reposition the Electronics Module above and to the front of the
analyzer. Lower the module into the analyzer so the screws at the four (4)
corners can be attached.
2. Attach the mounting plate of the Electronics Module to the analyzer as-
sembly using the four (4) screws you removed earlier.
PN 305892901, Rev S
Maintenance and Troublshooting | 4-21
