3050-RM Analyzer Replacement Parts
* Indicates recommended stock spare parts to have on hand.
Refer to the Figure numbers listed for the location of the part.
Part Description AMETEK Part No. Figure
Battery, Lithium 280750043 4-11
Fuse*, 2 Amp, 250 V 271291001 2-3
LCD Display with 6-inch cable 591132901 1-1
MCU Board 305110907S 4-9, 4-11
MFM – Mass Flow Meter 305449901S 4-4
PCB Assembly, Analog Interface 591144901 2-2, 2-3,
4-10
PCB Assembly, User Interface 591200901 4-12
Power Supply (±15 V, 5 V) T460-048 —
Power Supply (24 V) 271768001 4-9
Dryer 583072901S 2-4.1
Pressure Transducer 305450901S 4-5
Moisture Generator 305010901S 4-3, 4-4,
4-5, 4-6
*Sensor Assembly 305122901S 4-3
Sensor – Sour Natural Gas 305122902S —
Sensor – Carbon Dioxide 305122903S —
Capillary Tubes (Matched Set) 305431901S 1-2
Sample System Manifold 305002901S 1-2 4-4
Contaminant Trap 305921901 2-2, 4-8
Capillary Tubes (matched set) – For use with contaminant
trap or second dryer conguration.
305431903S 1-2 4-3
SAFETY CRITICAL COMPONENTS
Thermostat, Recognized/Certied component 269253001 —
Fan, Recognized/Certied component 271767001 4-7.1
PN 305892901, Rev S
Maintenance and Troublshooting | 4-3
