PN 305892901, Rev S
Electrical Requirements
The 3050-RM Moisture Analyzer must be installed in a general purpose or Divi-
sion 2 area. It does not have an On/O power switch so power must be applied
through a circuit breaker switch at the AC source.
General Purpose Installation:
• Power connection can be made using the supplied power cord(s) termi-
nated with a locally approved wall socket plug, or
• The analyzer can be hard-wired.
Sample Temperature and Pressure Requirements
Inlet sample temperature: 0 °C to 100 °C (32 °F to 212 °F)
Optimum input gas temperature: 60 °C ±5 °C (140 °F ±9 °F)
For optimum performance, the sample line should be heat traced to
maintain a constant sample temperature.
Minimum input pressure: 138 kPa (20 PSIG)
Maximum pressure: 345 kPa (50 PSIG)
If necessary, a pressure regulator can be installed at the main process shut-o
valve.
Installation and Start-Up | 2-5
