PN 305892901, Rev S
Restore conguration button
Restore the analyzer’s internal parameters from a le. The Open dialog
box appears so that you can select and open the le.
The Restore conguration button can also be used to restore the
analyzer communications parameters.
Live Data check box
Checked
The system connects to and uses live data from the analyzer.
Not checked
The system uses demonstration data.
Status message eld
Indicates if the analyzer is on-line, o-line, or in demo mode.
On-Line
The PC and analyzer are connected and communicating properly.
O-Line
The Live Data box is checked on the General tab and the connection
is broken or o-line.
Demo Mode
The Live Data box is not checked on the General tab. No analyzer is
connected through the serial port. This allows you to exercise program
options without communication with the analyzer.
Serial Numbers
The analyzer name and analyzer software version are displayed on the rst
line in the upper right-hand corner. The analyzer serial number and sen-
sor serial number, and the dryer code are also displayed.
In the lower right-hand corner, above the Help button, is the Congurator
Software version number.
Saving Analyzer Conguration Settings
To save all of the settings made on the General tab, click Apply.
To save settings and exit the program, click Apply+Exit.
To abort changes you have made, click Cancel+Exit. This will close the Con-
gurator Software program.
3-18 | 3050-RM Moisture Analyzer
