PN 305892901, Rev S
Installing the New Dryer/Trap
Minimize the time that the dryer is exposed to the atmosphere after
removing the protective caps. AMETEK recommends that the dryer be
exposed for less than a minute.
1. Insert the replacement dryer into the dryer port on the analyzer. Use the
new gaskets provided with the dryer in each of the ttings.
2. Tighten the ttings until they are nger tight.
3. Install the dryer mounting screws to secure the dryer to the bracket.
4. Tighten both of the ttings so that the nuts are 1/8
th
of a turn past nger
tight.
5. If you have a second dryer or trap. Repeat Steps 1 through 4 for the second
dryer or trap.
6. Place the Dryer Compartment Cover onto the rear of the analyzer and
secure with the four (4) captured screws.
7. Enter the production code for the new dryer.
The dryer production code is entered only once even if your analyzer is
equipped with two (2) dryers.
8. Power up the analyzer. Wait until the boot-up sequence is complete.
• Press TEST/CONFIG.
Scroll down to Production Codes and press Enter.
• Select Reference Dryer and press Enter to enter the production code.
Press Enter.
• Select Dryer Cong and choose either Single (for one dryer analyzer)
or Double, if your analyzer is equipped with two (2) dryers.
• Press Cancel several times to reverse through the menu and return to
the normal operating screen.
4-16 | 3050-RM Moisture Analyzer
