Ametek 3050-RM User Manual

PN 305892901, Rev S
Variables Table
Name ID HEX Description Type Typical Value
AnalogOutSpan 29 1D Analog output span Float 1.0
AnalogOutOset 30 1E Analog output oset Float 0.0
Baud 40 28 Serial communication speed Integer 9600
SerialMode 41 29 RS-485 two-wire or four-wire mode Integer 1(four-wire)
NodeAddress 42 2A RS-485 analyzer address String 1
AnalyzerName 43 2B AMETEK analyzer name String 3050-RM
Gas 44 2C Sample gas name String Nitrogen
Alarm1Hi 46 2E High concentration limit Float 100.0
Alarm1Lo 47 2F Low concentration limit Float 0.0
MaxCalError 55 37 Maximum verication error allowed Float Unused
KFactor 56 38 Gas based coecient Float 1.0
CalHour 57 39 Verication schedule parameter Integer 13
CalPeriod 58 3A Verication schedule parameter Integer 60
CalMonthDays 59 3B Verication schedule parameter Integer 1
CalWeekDays 60 3C Verication schedule parameter Integer 1
CalType 61 3D Verication schedule parameter Integer 0
SerialNumber 62 3E Analyzer manufacturing number String 315A001
CellSerialNumber 63 3F Sensor manufacturing code String 315715
MoistureGeneratorSN 64 40 Moisture generator production code String 020101305012
Version 65 41 Embedded software version String 1.00
HoldOut 69 45 Hold out during zero and verication Integer 1(hold)
VerDurationLimit 71 47 Minimum verication cycles number Integer 30
EnableAlarm1 73 49 Enable or disable concentration alarm Integer 1(enable)
DryerDateCode 75 4B Dryer production code String 010080009
DryerPpmHours 76 4C Dryer consumption in 1000 ppm hours Float 200.00
LCDcontrast 79 4F Display contrast setting Integer 5
LCDbacklight 80 50 Display back light on or o Integer 1 (on)
Pressure1 87 57 Sensor pressure value Float 14.7 psi
CellTemp 88 58 Sensor temperature value Float 60.0 degree C
AnalogOutput 89 59 Current output reading Float 12.0 mA
EETemp 90 5A Electronics enclose temperature Float 55.0 degree C
Moisture 91 5B Moisture concentration reading Float 20.0 ppm
HeldConc 92 5C Held moisture concentration reading Float 20.0 ppm
Frequency 93 5D Sensor frequency reading Float 1200 Hz
DeltaFrequency 94 5E Wet minus dry reading Float 24.7 Hz
Flow3 97 61 Held and displayed ow Float 50.0 sccm
ValveState 99 63 0-sample, 1-ver, 2-reference, 3-zero Integer 0(sample)
Hour 100 64 Analyzer current time read Integer 13
Figure 2-21.1.
Variables table.
Installation and Start-Up | 2-27
