Name ID HEX Description Type Typical Value
Minute 101 65 Analyzer current time read Integer 36
Second 102 66 Analyzer current time read Integer 10
Month 103 67 Analyzer current time read Integer 12
Day 104 68 Analyzer current time read Integer 5
Year 105 69 Analyzer current time read Integer 2004
Date 106 6A Analyzer current date String 02/24/04
Time 107 6B Analyzer current time String 08:45
SystemState 108 6C Alarm status word Integer 1024
DataState 110 6E Data ready variable Integer 0
ModelName 119 77 Analyzer model name String 3050-RM
ReferencePer 120 79 Current reference period time Integer 15
SamplePer 121 79 Current sample period time Integer 21
WetFreq 122 7A Wet frequency reading Float 1254.7 Hz
DryFreq 123 7B Dry frequency reading Float 1230 Hz
WeekDay 124 7C Current day of the week Integer 1
MoistureSpan 125 7D Concentration coecient Float 1.0
CalCycle Count 126 7E Verication cycles countdown timer Integer 15
EquilCal 129 81 Equilibration cycles number set Integer 3
FrequencyOset 131 83 Zero correction coecient Float 0.0
Font 156 9C Display font ag Integer 0
BypassState 159 9F State of bypass valve Integer 1(closed)
MoistureUnits 168 A8 Moisture units of measure set Integer 0
PpmW 169 A9 PpmV to ppmW conversion factor Float 0.6431
IgnoreSpanDrift 170 A10 Ignore span drift ag Integer 0
OldMoistSpan 171 AB Moisture span before the correction Float 0.0
Figure 2-21.2.
Variables table (continued).
2-28 | 3050-RM Moisture Analyzer
