PN 305892901, Rev S
To highlight an item, scroll through the menu items until the small arrowheads
point to your choice as shown in Figure 2-12. Up and down arrow symbols dis-
played on the right-hand side of the screen indicate that there are more menu
items above or below the currently displayed items.
Figure 2-12.
Display showing alarm sub-
menu with arrowheads for
highlighting menu items.
Alarm
< High Limit >
Low Limit
Line indicates more
menu choices above or
below
Arrowheads indicate
highlighted menu
choice.
Once a menu has been accessed, use the arrow keys to scroll through the
menu until the desired item is highlighted. Press Enter to select the menu
item. Depending on the selected menu item, more menus will be displayed or
data may be entered. Follow the instructions on the display.
Except where otherwise noted:
Key Function
Press Enter Save changes and return to previous menu.
Press Cancel To exit without saving when entering data. (Any changes
made will not be saved.)
To go back through previous levels, one level at a time, until
the display returns to the normal operation screen, when
browsing the menu list.
2-18 | 3050-RM Moisture Analyzer
