Rammax 1515-M/-MC/-MI/-MCI
Index: a; Issued 08/2010
Abb. S2: Shut down yoke unlo-
cked
Abb. S1: Shut down yoke locked
This protects you from the machine jamming or being over-
run when moving backwards. You can only move the machi-
ne forwards and away from an obstruction if it is activated.
You can only move in reverse again after you have moved the
shut down yoke back into the "Unlocked“ position. The shut
down yoke must be unlocked before you can use the machine
again.
Always use the shut down yoke to lock the machine when:
transporting it,
maintaining it,
reparing it or
parking it.
Unlock using the shut down yoke:
Holding the shut down yoke tightly with your left hand.
Pull out the spring-loaded locking bar with your right hand
until the shut down yoke is visually unlocked (Fig. S3).
Abb. S3: Unlocking the shut down yoke
Now use your left hand to move the shut down yoke
upwards.
The shut down yoke is now unlocked.
Locking using the shut down yoke:
USe both hands to press the shut down yoke downwards
until it visually locks into place (Fig. S4).
•
•
•
•
safety
