Ammann Rammax 1515-M - Fast Traverse Button

56
Rammax 1515-M/-MC/-MI/-MCI
Index: a; Issued 08/2010
Fig. SE11 Traverse forward using remote cable controller
Press button
2
and
6
simultaneously to move the machine
backwards.
Fig. SE12 Traverse backward using remote cable controller
Press button
1
and
6
simultaneously to turn the machine
in position.
Fig. SE13 Turn right using remote cable controller
Fast traverse button
This button is used to switch fast traverse On and Off. The
machine moves twice as fast as normal mode when switched
to fast traverse. The fast traverse function can only be used in
conjunction the traversing function.
The fast traverse button has two switch positions: Fast traver-
se switched off and fast traverse switched on. The diode on
the button illuminates (Fig. SE15) when fast traverse is switched
on.
