75
Rammax 1515-M/-MC/-MI/-MCI
Index: a; Issued 08/2010
Use chocks to secure the transport vehicles wheels in place.
Use the remote cable or infrared controller (if tted) to move
the machine up onto the transport vehicle. This will enable
you to stand away from the immediate danger area.
Always stand by the incline when moving the machine onto or
off of the transport vehicle (Fig. MT9)
Fig. MT9 Going up an incline
Securing the machine for transport
Only use suitable slings to secure the machine for transpor-
ting.
The edges of the transport-eyes are sharp. Always use edge
protectors when using bre ropes. They will protect the bre
ropes from being damaged.
Lock the shut down yoke in place.
Put the chock blocks
K
on both sides of the machine
centrally under the drums. ► The chock blocks must be
aligned opposite to each other, since the machine could
otherwise move in one direction.
Fig. MT10 Correctly positioned
K
Fig. MT11 Wrongly positioned
1)
2)
transporting the Machine
