33
Rammax 1515-M/-MC/-MI/-MCI
Index: a; Issued 08/2010
Fig. S4: Locking the shut down yoke
The shut down yoke is now locked.
In-situ and remote shutting down
In-situ and remote shutting down processes are only appli-
cable to machines equipped with remote infrared controllers.
The processes are integrated in the machine's electronic con-
trol system. The machine will be stopped if either of them is
activated. The engine will continue to run but all other func-
tions will be stopped. It can only be used again after in-situ or
remote shut down has been de-activated.
In-situ shutting down will be activated whenever the distance
between the remote infrared controller and the machine drops
to less than two metres. Increase the distance to de-activate
this function. You must ensure that the in-situ shut down does
not react to people that approach the machine. It must only
react to the remote infrared controller.
Remote shut down will be activated whenever the distance
between the remote infrared controller and the machine in-
creases to more than twenty metres. Reduce the distance to
de-activate this function.
Remote shut
down
Active range
In-situ shut down
Fig. S5: Remote infrared controller
safety
