7.4 Automatic Measurement Commands
7-45
7
Remote Commands
:SENSe:MEASure:EMARgin:MARGin:SLOT
<slot>,<interface>,<boolean>[,<unit>]
Parameter <slot>=<CHARACTER PROGRAM DATA>
SLOT1 to SLOT6 Slots No. 1 to No. 6
1 to 6 when using the MP1800A, 1 to 4 when using the MT1810A
USB11 to USB14 USB No.11 to 14
<interface>=<DECIMAL NUMERIC PROGRAM DATA>
1 to 4 Data1 to 4
Fixed to 1 if using a USB module.
<boolean>=<BOOLEAN PROGRAM DATA>
ON or 1 ON
OFF or 0 OFF
[<unit>]=<DECIMAL NUMERIC PROGRAM DATA>
1 to 4 Mainframe Nos. 1 to 4
When using two or more MT1810A units in serial connection, specify the
mainframe number.
Can be omitted. Mainframe No. 1 is specified when omitted.
Function Selects the Eye Margin measurement slot.
Example To set Eye Margin measurement of USB No.11 to ON:
> :SENSe:MEASure:EMARgin:MARGin:SLOT USB11,1,ON
Compatibility Incompatible with existing models.
:SENSe:MEASure:EMARgin:MARGin:SLOT? <slot>,<interface>[,<unit>]
Parameter <slot>=<CHARACTER PROGRAM DATA>
SLOT1 to SLOT6 Slots No. 1 to No. 6
1 to 6 when using the MP1800A, 1 to 4 when using the MT1810A
USB11 to USB14 USB No.11 to 14
<interface>=<DECIMAL NUMERIC PROGRAM DATA>
1 to 4 Data1 to 4
Fixed to 1 if using a USB module
[<unit>]=<DECIMAL NUMERIC PROGRAM DATA>
1 to 4 Mainframe Nos. 1 to 4
When using two or more MT1810A units in serial connection, specify the
mainframe number.
Can be omitted. Mainframe No. 1 is specified when omitted.
Response <boolean>=<NR1 NUMERIC RESPONSE DATA>
1 ON
0 OFF
Function Queries whether the specified slot is subject to Eye Margin measurement.
Example To query whether USB No.11 is subject to measurement:
> :SENSe:MEASure:EMARgin:MARGin:SLOT? USB11,1
< 1
Compatibility Incompatible with existing models.
