7.4 Automatic Measurement Commands
7-51
7
Remote Commands
Table 7.4.2.1-3 Eye Margin Measurement Results <result>
Form Format Description
Form1
Phase type
" XXXX" For 0 to MAX (mUI/ps)
Displays in the selected unit.
"Failed" For measurement failure
"------" When no data corresponds to the
query.
Form2
Threshold type
" XXXX" 0 to MAX (mVpp)
"Failed" For measurement failure
"------" When no data corresponds to the
query.
Function Queries the Eye Margin measurement results.
Example To query the Eye Margin measurement results of USB No.11:
> :CALCulate:DATA:EMARgin? USB11,1, "THReshold"
< " 0"
Compatibility Incompatible with existing models.
:CALCulate:DATA:EMARgin:STATus?
Response <string>=<STRING RESPONSE DATA>
"" When no alarm exists
"Sync Loss" Sync. Loss
"Clock Loss" Clock Loss
"Out of range" Out of range
"Illegal Error" Illegal Error
"Meas. Threshold exceeded" Number of errors exceeds the target rate
Note:
When two or more alarms have occurred, they are displayed in the
following order:
Illegal Error>Clock Loss
>Sync Loss>Out of range
Function Queries the Eye Margin measurement status.
Example > :CALCulate:DATA:EMARgin:STATus?
< "Sync Loss"
Compatibility Incompatible with existing models.
