Chapter 7 Remote Commands
7-50
:SENSe:MEASure:EMARgin:ELAPsed?
Response <day>=<NR1 NUMERIC RESPONSE DATA>
0, 1 to 99 0 to 99 days
<hour>=<NR1 NUMERIC RESPONSE DATA>
0 to 23 0 to 23 hours
<minute> = <NR1 NUMERIC RESPONSE DATA>
0 to 59 0 to 59 minutes
<second> = <NR1 NUMERIC RESPONSE DATA>
0 to 59 0 to 59 seconds
Note:
The following is output when no measurement is performed:
< 0,0,0,0
Function Queries the Eye Margin measurement elapsed time (Elapsed Time).
Example > :SENSe:MEASure:EMARgin:ELAPsed?
< 99,23,59,59
Compatibility Compatible with the MP1632C.
:CALCulate:DATA:EMARgin? <slot>,<interface>,<string>[,<unit>]
Parameter <slot>=<CHARACTER PROGRAM DATA>
SLOT1 to SLOT6 Slots No. 1 to No. 6
1 to 6 when using the MP1800A, 1 to 4 when using the MT1810A
USB11 to USB14 USB No.11 to 14
<interface>=<DECIMAL NUMERIC PROGRAM DATA>
1 to 4 Data1 to 4
Fixed to 1 if using a USB module
<string>=<STRING PROGRAM DATA>
For details on <string>, refer to Table 7.4.2.1-2.
[<unit>]=<DECIMAL NUMERIC PROGRAM DATA>
1 to 4 Mainframe Nos. 1 to 4
When using two or more MT1810A units in serial connection, specify the
mainframe number.
Can be omitted. Mainframe No. 1 is specified when omitted.
Table 7.4.2.1-2 Eye Margin Measurement Items <string>
Item <string> Response form
Phase margin "PHASe" Form1
Threshold margin "THReshold" Form2
Period "PERiod" Form1
Response <result>=<STRING RESPONSE DATA>
For details on the measurement data <result>, refer to the table below.
To Next Page
