Chapter 7 Remote Commands
7-62
:DISPlay:RESult:EDIagram:TEMPlate:SELect <type>
Parameter <type>=<CHARACTER PROGRAM DATA>
E1 Edit1
E2 Edit2
E3 Edit3
E4 Edit4
Function Sets the mask pattern for performing the Eye Diagram mask test.
Example To set the mask pattern for performing the Eye Diagram mask test to Edit2:
> :DISPlay:RESult:EDIagram:TEMPlate:SELect E2
Compatibility Incompatible with existing models.
:DISPlay:RESult:EDIagram:TEMPlate:SELect?
Response <type>=<CHARACTER RESPONSE DATA>
E1, E2, E3, E4
Function Queries the mask pattern for performing the Eye Diagram mask test.
Example > :DISPlay:RESult:EDIagram:TEMPlate:SELect?
< E2
Compatibility Incompatible with existing models.
:DISPlay:RESult:EDIagram:TEMPlate:THReshold <thre>
Parameter <thre>=<CHARACTER PROGRAM DATA>
E_3 to E_12 1E–3 to 1E–12/1 Step
Function Sets the Error Threshold for performing the Eye Diagram mask test.
Example To set the Error Threshold for performing the Eye Diagram mask test to
E–3:
> :DISPlay:RESult:EDIagram:TEMPlate:THReshold E_3
Compatibility Incompatible with existing models.
:DISPlay:RESult:EDIagram:TEMPlate:THReshold?
Response <thre>=<CHARACTER RESPONSE DATA>
Function Queries the Error Threshold for performing the Eye Diagram mask test.
Example > :DISPlay:RESult:EDIagram:TEMPlate:THReshold?
< E_3
Compatibility Incompatible with existing models.
:DISPlay:RESult:EDIagram:SCALe:ASCale
Function Automatically adjusts the Eye Diagram measurement graph scale.
Example > :DISPlay:RESult:EDIagram:SCALe:ASCale
Compatibility Incompatible with existing models.
