Chapter 7 Remote Commands
7-102
:DISPlay:RESult:BATHtub:SCALe:VERTical <max>,<min>
Parameter <max>,<min>=<DECIMAL NUMERIC PROGRAM DATA>
Table 7.4.4.2-3 Parameters
Form <max> <min>
Histogram Type 6 to 15 (E+6 to E+15) Input 0
Error Rate Type 2 to 7 (E–2 to E–7) 8 to 15 (E–8 to E–15)
Note:
In case of the Error Rate type, the difference between the
maximum and minimum value must be at least 6, and the value
must be an even number.
Function Sets the vertical scale of the graph display during Bathtub measurement.
Example To set the scale during Error Rate type display to maximum E–4 and
minimum E–10:
> :DISPlay:RESult:BATHtub:SCALe:VERTical 4,10
Compatibility Incompatible with existing models.
:DISPlay:RESult:BATHtub:SCALe:VERTical?
Response <min>,<max>=<NR2 NUMERIC RESPONSE DATA>
Parameters are the same as those
for :DISPlay:RESult:BATHtub:SCALe:VERTical.
<min> is omitted if the measurement item is histogram.
Function Queries the vertical scale of the graph display during Bathtub
measurement.
Example > :DISPlay:RESult:BATHtub:SCALe:VERTical?
< 4,10
Compatibility Incompatible with existing models.
