Chapter 7 Remote Commands
7-106
:CALCulate:DATA:BATHtub? <string>
Parameter <string>=<STRING PROGRAM DATA>
<result1> For details on measurement data <result1>, refer to
Table 7.4.4.3-2.
<result2> For details on immediate data <result2>, refer to Table
7.4.4.3-3.
<result3> For details on statistic data <result3>, refer to Table
7.4.4.3-4.
Table 7.4.4.3-2 Phase vs. BER Measurement Result <result1>
Item <Result1>
Response
Format
Phase vs BER
(Phaseand Error Rate)
Number of
measurements
1 to 1000
"BATH:1"..."BATH:1000" Form1
Histogram
(Phase and Error Count)
"HIST:1"..."HIST:1000" Form2
The measurement result for each Phase is delimited by a comma (,) and
returned.
Table 7.4.4.3-3 Phase vs. BER Immediate Data <result2>
Item <Result2>
Response
Format
Optimum BER
Number of
measuremen
ts
1 to 1000
"OPTBer:1"... "OPTBer:1000" Form3
Optimum Phase "OPTPh:1"... "OPTPh:1000" Form4
Total Jitter "TJ:1"... "TJ:1000" Form4
Deterministic Jitter "DJ:1"... "DJ:1000" Form4
Random Jitter "RJ:1"... "RJ:1000" Form4
J2 "J2:1"... "J2:1000" Form4
J9 "J9:1"... "J9:1000" Form4
Table 7.4.4.3-4 Phase vs. BER Measurement Statistic Data <result3>
Item <Result3>
Response
Format
Total Data "TOTal" Form5
Valid Data "VALid" Form5
Total Jitter Mean "TJMean" Form4
Deterministic Jitter Mean "DJMean" Form4
Random Jitter Mean "RJMean" Form4
J2 Mean "J2Mean" Form4
J9 Mean "J9Mean" Form4
