Appendix E Sequence Examples
E-4
E.2 Initialization
This section describes an example procedure for enabling MUX and
DEMUX after initializing the system.
Table E.2-1 Initialization procedure example
Remote Commands Explanation of Commands
:UENT:ID 1
:SYST:MEM:INIT
Wait 10000 ms.
*
2
:UENT:ID 1;:MOD:ID 6
:SYST:INP:CSEL INT1
Wait 1000 ms.
*
2
:UENT:ID 1;:MOD:ID 3
:SYST:INP:CSEL INT2
Wait 1000 ms.
*2
:SYST:OUTP:CRAT FULL
:MCOM:OPER:SETT 2
Wait 5000 ms.
*
2
:USB:ID 7
:SYST:LINK:MUXP ON
Wait 3000 ms.
*
2
:UENT:ID 1;:MOD:ID 4
:MCOM:OPER:SETT 2
Wait 5000 ms.
*
2
:USB:ID 11
:SYST:LINK:DEM ON
Wait 3000 ms.
*
2
Sets the remote command destination to
MP1800A.*
1
Initializes the system.
Initialization takes up to 10 seconds to complete.
Sets the remote command destination to Jitter
Module.*
1
Links the Jitter Module and Synthesizer.
Link setting requires about one second.
Sets the remote command destination to PPG.*
1
Links the PPG and Jitter Module.
Link setting requires about one second.
Sets the PPG Clock Output to "Full Rate".
Sets the PPG combination to "2ch".
Combination setting requires about five seconds.
Sets the remote command destination to MUX.*
1
Links the PPG and MUX.
Link setting requires about 3 seconds.
Sets the remote command destination to ED.*
1
Sets the ED combination to "2ch".
Combination setting requires about five seconds.
Sets the remote destination to DEMUX.*
1
Links the ED and DEMUX.
Link setting requires about 3 seconds.
*1: Sets the remote command destination for the MX180000A Main
Application.
*2: Wait indicates the recommended wait time for the MX180000A
before transmitting the next command. This command is not
supported by the MP1800A.
