Appendix E Sequence Examples
E-6
E.3 Setting Examples of Measurement Conditions
E.3.1 Setting example of Test Conditions - Pattern, Measurement -
This section describes an example procedure for setting measurement
conditions.
Test Pattern, Measurement settings apply to the PPG/ED linked to the
MUX/DEMUX.
Table E.3.1-1 Setting example of Test Pattern and Measurement
Remote Commands Explanation of Commands
:UENT:ID 1;:MOD:ID 3
:SOUR:PATT:TYPE PRBS
:SOUR:PATT:PRBS:LENG 31
:UENT:ID 1;:MOD:ID 4
:SENS:PATT:TYPE PRBS
:SENS:PATT:PRBS:LENG 31
:SENS:MEAS:EAL:MODE SING
:SENS:MEAS:EAL:UNIT CLOC
:SENS:MEAS:EAL:CLOC E_12
Sets the remote command destination to PPG.
Sets the PPG Test Pattern to "PRBS31".
Sets the remote command destination to ED.
Sets the ED Test Pattern to "PRBS31".
Sets the ED measurement mode to "single".
Measurement stops when the following
measurement cycle conditions are satisfied.
Sets the ED measurement cycle units to "Clock".
Sets the ED measurement cycle to a Clock Count
of 1E + 12.
E.3.2 Setting example of Test Conditions - RF Output / Input -
This section describes an example procedure for setting the functions
displayed in the MUX "Data Interface tab" or DEMUX "Interface tab".
Table E.3.2-1 Setting example of Data Input/Output
Remote Commands Explanation of Commands
:USB:ID 11
:DEM:DATA:INT DIF50
:DEM:DATA:DIFF ALT
:USB:ID 7
:MUX:DATA:TRAC ON
:MUX:DATA:AMPL DATA,0.500
Sets the remote command destination to DEMUX.
Sets the DEMUX Data Input Condition to
"Differential 50ohm" "Alternate".
Sets the remote command destination to MUX.
Sets the MUX Data and Xdata output conditions to
the same values.
Sets the MUX Data Output Amplitude to "0.5
Vpp".
