Chapter 3 Measurement
3-64
Output Impedance Reference
■
Summary
Sets the impedance reference used for converting power to dBm.
When the output level is set in power, specify the impedance value
of the DUT to connect to the Audio Generator. The output level of
the Audio Generator can be set in either voltage or power. The
voltage value and power value are converted to each other by the
following calculation formula.
dBm10
1000
Table 3.5.1-1 Relationship between Output Impedance and Output Impedance Reference
■
Setting range
0.01 to 1 000 000 000.00
Output Impedance (Rs)
Output Impedance Reference (Rr)
Audio Generator function
Vrms
