Arris NVG599 - Page 58

Administrator’s Handbook
58
The following table shows VoIP line states during various conditions.
The following table provides the state changes during the boot-up procedure.
VoIP Line
1/2
Hook state WAN IP Reg-state
FXS
Voltage
Tone LED
Disabled
On/Off-hook Up Idle Off N/A Off
Enabled
On-hook Up Registered On N/A Solid
Enabled
Off-hook Up Registered On Dial tone Blink
Enabled
On/Off hook Up Failure Off N/A Off
Enabled
On/Off hook Down Idle Off N/A Off
VoIP Line
1/2
WAN Status Hook State Reg-state
FXS
Voltage
Tone LED
Disabled
Down Off-hook Idle On-to-off Off Off
Enabled
Down On/Off-hook Idle On Congestion Off
Enabled
Up Off-hook Registered On Congestion.
Dial Tone played
after the hook
state is
changed.
On
