Arris NVG599 - LED Function Summary Matrix

91
LED Function Summary Matrix
Power
Solid Green =
The device is
powered.
Flashing Green =
A power-on self-
test (POST) is in
progress.
Orange/Amber =
Firmware
upgrade (see
“Power during
Firmware
Upgrade” on
page 88)
Flashing Red = A
POST failure (not
bootable) or
device malfunc-
tion occurred.
* When the
device encoun-
ters a POST fail-
ure, all indicator
lights on the
front of the
device continu-
ously flash.
Off = The unit
has no AC power.
Battery
Solid Green =
Battery in place
but not being
used.
Flashing Green =
Battery charging.
Solid Amber =
Battery in use.
Flashing Amber =
Low battery.
Solid Red = Bat-
tery backup
mechanism has a
fault.
Flashing Red =
Battery needs to
be replaced.
Off = No battery
or battery has no
charge.
Cycle between
all colors = Bat-
tery conducting
self-test.
Ethernet
Solid Green =
Powered device
connected to the
associated port
(includes devices
with wake-on-
LAN capability
where a slight
voltage is sup-
plied to the
Ethernet connec-
tion).
Flashing Green =
Activity seen
from devices
associated with
the port. The
flickering of the
light is synchro-
nized to actual
data traffic.
Off = The device
is not powered,
no cable or no
powered devices
connected to the
associated ports.
WiFi
Solid Green = Wi-
Fi is powered.
Flashing Green =
Activity seen
from devices
connected via
Wi-Fi. The flick-
ering of the light
is synchronized
to actual data
traffic.
Off = The device
is not powered
or no powered
devices con-
nected to the
associated ports.
HomePNA
Solid Green =
Powered device
connected to the
associated port
(includes devices
with wake-on-
LAN capability
where a slight
voltage is sup-
plied to the
Ethernet connec-
tion).
Flickering Green
= Activity seen
from devices
associated with
the port. The
flickering of the
light is synchro-
nized to actual
data traffic.
Off = The device
is not powered,
no cable or no
powered devices
connected to the
associated ports.
