iHP Manual 135 | P a g e
iHP Owners Manual
Command
Code
Command Name
Definition
Bit13
Reserved
Bit12
Reserved
Bit11
Vin3OVP
Bit10
Vin2OVP
Bit9
Vin1OVP
Bit8
Vin3UVP
Bit7
Vin2UVP
Bit6
Vin1UVP
Bit5
AUX
Bit4
Relay
Bit3
Supply
Bit2
PSON
Bit1
Address
Bit0
BulkOK
Index 01 “PFC Status”
Bit
Bit Name
Bit15
Reserved
Bit14
Reserved
Bit13
Reserved
Bit12
Reserved
Bit11
Reserved
Bit10
Reserved
Bit9
Reserved
Bit8
OPW
Bit7
OCW
Bit6
OVW
Bit5
Other
Bit4
SCKT
Bit3
OCP
Bit2
UVP
Bit1
OVP
Bit0
OutOK
Index 02 “VBUS Status”
Bit
Bit Name
Bit15
Reserved
Bit14
Reserved
Bit13
Reserved
Bit12
Reserved
Bit11
Differential Voltage Protection Rail3
Bit10
Differential Voltage Protection Rail2
Bit9
Differential Voltage Protection Rail1
