Artesyn iHP - Current Sharing Signal (ISHARE); D_Rtn; Voltage Monitor (VMON)

iHP Manual 57 | P a g e
iHP Owners Manual
Table 4-10
IMON
Output Current
0V
0% Nominal Output Current
2.5V
25% Nominal Output Current
5V
50% Nominal Output Current
7.5V
75% Nominal Output Current
10V
Nominal Output Current
4.2.1.2.4 Voltage Monitor (VMON)
VMON J2 Pin 11 is an output signal. VMON functions as the voltage monitor signal of the module. It reports
the sensed output voltage with a scaled voltage between 0 and 0V. D_RTN J2 Pin 7 is used for twisted pair
cabling with VMON.
Table 4-11
VMON
Output Voltage
0V – 0.42V
5% Nominal Output Voltage
2.5V
30% Nominal Output Voltage
5V
60% Nominal Output Voltage
7.5V
90% Nominal Output Voltage
8.33V
100% Nominal Output Voltage
10V
120% Nominal Output Voltage
4.2.1.2.5 Current Sharing Signal (ISHARE)
ISHARE J2 Pin 10 signal is used for active current sharing. Interconnecting the ISHARE signal of the modules in
a star connection activate the active current sharing circuitry. Active current sharing is required when modules
are connected in parallel. The module’s ISHARE signal and D_RTN J2 Pin 4 should be star connected. This will
reduce the introduction of DC offset and noise to the signals.
4.2.1.2.6 D_RTN
D_RTN (J2 Pin2 and Pin7) is used for twisted pair cabling of IMON and VMON signal to reduce noise pick up.
 D_RTN (J2 Pin2) is used for twisted pair cabling with IMON.
 D_RTN (J2 Pin7) is used for twisted pair cabling with VMON.
 D_RTN (J2 Pin4) is used as return ground for the ISHARE signal.
