It is required to enable the “Module Synchronized OFF” functionality when module is connected in parallel or
series.
5.1.4.2 Module Group
Modules need to be group as one during parallel or series connections. This function will treat all modules as
one.
Once grouped, the system will have the below added functions:
 Single command for all modules in a group (limited command)
 Single Register Status reporting for all modules in a group
 Single Reporting of Vo, Io, and Po for all modules in a group
User will need to configure in the ISOCOMM WebTool, the group number, if the modules in the group are
connected in parallel or series, and which group the module should be included.
Note: Modules will be allowed to be included in one group only. Module grouping function is discussed in
Section 6.
5.1.5 Firmware Section
This section provides instruction for firmware upgrade of PFC and module devices.
Before upgrading the firmware, module outputs should be disconnected to system load. PFC can be
bootloaded with or without modules inserted to the iHP rack.
Procedure for firmware upgrade (PFC and Module):
 Power on AC source based on the input configuration of the unit.
 Unit will be operational after 20 seconds boot-up.
 Open Google Chrome Browser.
 Type the IP address of the iHP to proceed with the iHP WebTool page.
