iHP Manual 95 | P a g e

iHP Owners Manual

5.1.4.1 Module Synchronized OFF

This function will shut down all modules installed in an iHP rack when any module is at fault or in standby

mode.

User can configure this function.

Setting

Remarks

Enable

All modules installed in the iHP rack will shut down when any module is at fault or in standby

mode.

Disable

When at least one module is at fault or in standby mode, the remaining modules will still be

operational.
