4.1.3 ISOCOMM Default Settings
Table 4.2 contains ISOCOMM default settings of the iHP rack when shipped from Artesyn. The ISOCOMM
setting definition is in Section 5.1.
Table 4-2
ISOCOMM WebTool Section
User
Configurable
Parameter
Default Setting when
shipped from Artesyn
User Configurable
NETWORK
DHCP
Disable*
Yes
Static IP Address
192.168.2.100
Yes
CAN/RS485
RACK Address
0
Yes
RACK
Internal Ambient
Temperature OTP
62
o
C
Yes
INH0/EN0 TTL Function
Inhibit
Yes
INH1/EN1 TTL Function
Inhibit
Yes
Wait for Power Switch
Enable
Yes
Disable on 5V_STBY
Fault
Disable
Yes
RACK Synchronized Off
Disable
Yes
Numbers of Racks
Connected
1
Yes
MODULE
Module Synchronized
Off
Enable
Yes
Module Grouping
No Grouping
Yes
Note: * - Model revision AZ or later for 73-958-0001, model revision AH or later for 73-958-0001L & 73-958-
0001S are set by default to DHCP.
4.2 Module and Rack Hardware Signals
This section contains a description of module and rack analog and digital hardware signals that the users can
use based on their requirements or applications. For module command information, please refer to Appendix
B.2 Module Command.
