iHP Manual 66 | P a g e
iHP Owners Manual
will re-initialize, the Module Operational Command (01h) and Module Write Protect Command (10h) will be
set to enable. The module output will be ON and set to nominal V out.
Table 4-17 lists the status of the module command and the functionality of the commands when configuring
the module to DVS mode.
Table 4-16
Module Command
Command Name
Functional
in DVS
Upon Change to DVS
B1h
VREF
Yes
Set to the module’s nominal output voltage.
B2h
IREF
Yes
IREF is the output current level in which the
module will enter to Constant Current Source.
During 52h set to Constant Current, value will be
set based on Module Command 4Dh and nominal
output current.
During 52h set to Latch Type, although the Latch
level can be adjusted, the IREF value will be fixed
to 120% of the nominal output current.
48h
OV_FAULT_LIMIT_MULTIPLIER
Yes
No change from previous value
49h
OV_WARN_LIMIT_MULTIPLIER
Yes
No change from previous value
4Bh
UV_FAULT_LIMIT_MULTIPLIER
Yes
No change from previous value
4Ch
UV_WARN_LIMIT_MULTIPLIER
Yes
No change from previous value
4Dh
OC_FAULT_LIMIT_MULTIPLIER
Yes
No change from previous value
52h
OC_RESPONSE_TYPE
Yes
Set to Constant Current Protection
B5h
SET_VOLTAGE_RISE_SETTING
Yes
No change from previous value
B6h
SET_CURRENT_RISE_SETTING
No
No change from previous value
B7h
SET_IO_ACTIVE_LEVEL_LOGIC
Yes
No change from previous value
B8h
SET_MODULE__LOAD_TYPE
Yes
Default to capacitive load type Data “02h”
BAh
ANALOG_FILTER_ENABLE
No
No change from previous value
*Functional: If Yes, Module Command is operational during the module mode.
If No, Module Command is not operational during the module mode
To change module output voltage, a B1h (VREF) command to the module.
Device Address
Module Command
Data
<Module Slot Address>
B1h
< Data is the Set Voltage in hexadecimal>
*Before writing to the module, please ensure that the Module Command Write Protect (10h) is disabled.
*Please refer to Section 5.2 for Module User Configurable Parameters or Appendix B.2 Module Command
The user can program the module’s output voltage within 5% to 120% of the nominal output voltage rating of
the module. For example, a 24V module has a nominal voltage of 24V and can be set to operate between 1.2V
and 28.8V.
