iHP Owners Manual
6.5 Accepted Group Commands using Group Device Address
Above commands have the same function as specified in Appendix B.2 Module Command. When users send
above WRITE command with Group address, all modules included in that Group will receive the WRITE
command at the same time.
6.6 Accepted Group Commands using ISOCOMM Device Address
Command
Command Name
D3h
MODULE_CONFIG
B5h
V Rise time
B6h
I Rise time
B8h
SET_MODULE__LOAD_TYPE
Above command functions are specified in Appendix B.3 ISOCOMM Command.
6.7 Group Status and Reporting
When reading STATUS and Reporting, device address of the group should be used.
Command
Command Name
Remarks
0x78h
STATUS_BYTE
ISOCOMM will read each module STATUS_BYTE reporting.
ISOCOMM will perform OR operation of STATUS_BYTE of all
modules belonging to the group.
0x79h
STATUS_WORD
ISOCOMM will read each module STATUS_WORD reporting.
ISOCOMM will perform OR operation of STATUS_WORD of all
modules belonging to the group.
Command
Command Name
01h
OPERATION
03h
CLEAR_FAULTS
10h
WRITE_PROTECT
48h
OV_FAULT_LIMIT_MULTIPLIER
4Bh
UV_FAULT_LIMIT_MULTIPLIER
4Dh
OC_FAULT_LIMIT_MULTIPLIER
52h
OC_RESPONSE_TYPE
B1h
VREF
B2h
IREF
B7h
SET_IO_ACTIVE_LEVEL_LOGIC
BAh
ANALOG_FILTER_ENABLE
