Table 1-5
OUTPUT – Module in Voltage Source Mode
Voltage Source
MODULE CODE
SL
SQ
SW
S8
S1
SA
S2
Nominal
Output (V)
12
24
48
80
125
200
250
Setting
Range (V)
0.6 V - 14.4 V
1.2 V - 28.8 V
2.4 V - 57.6 V
4.0 V - 96.0 V
6.25 V - 150.0 V
10.0 V – 240.0 V
12.5 V - 300.0 V
Low Frequency
RMS Ripple (mV)
24
48
96
160
250
500
500
Line
Regulation (mV)
12
24
48
80
125
200
250
Load
Regulation (mV)
24
48
96
160
250
400
500
P-P Ripple (mV)
60
120
240
400
625
1250
1250
Drift
(Temp Stability)
±0.05% of Iout Rated over 8 hours, after 30-minute warm up, constant Line, Load and Temp
Temp
Coefficient
(PPM/°C)
200
Pgm
Accuracy (mV)
Digital: 0.1% of Nominal Output Voltage; Analog: 1.0% of Nominal Output Voltage
Pgm
Resolution (mV)
SL=TBD; SQ=1; SW=2; S8=8; S1=6; SA=21; S2=21
Meas
Accuracy (mV)
0.2% + 0.2% of Nominal Output Voltage
Meas
Resolution
SL=TBD; SQ=1; SW=2; S8=8; S1=6; SA=21; S2=21
Transient
Response
Max 5.0% deviation from current set point must recover within 1mS for a 50% step load.
Current Sense
Method
Internal Shunt; External Shunt can be used for better temperature stability.
