iHP Manual 89 | P a g e

iHP Owners Manual

In below screen shot, there are three iHP rack in multi-rack operation. The WebTool will display the IP address

of the other two racks connected.

5.1.2 Network Section

Network configuration can be done using this section in the WebTool. The Network Section contains the

following information:

 Ethernet Settings

 MAC Address

 Current IP Address

 Broadcast Address

 DHCP Setting

 Static IP Address (when DHCP is disable)

 CAN/RS485 Settings

In the Network Section user can configure the following:

 Enable/Disable DHCP

 Static IP Address

 CAN/RS485 Rack Address
